4.5.4.861 -> 4.5.4.910

Summary of Changes for VidCAD SQL 4.5 (4.5.4.861 -> 4.5.4.910)

Release Date: November 24, 2014

Main Menu

NEW - Compatibility with BricsCAD V15
-Look for working dynamic block grips that are used for our router and jack borders!

-Resolved issue with Virtual Folders not importing correctly during the import/export or Check in/Check out processes.

-Resolved issue with Main Menu not regreshing after Virtual Folders are created.

-Resolved issue where VidCAD was allowing trailing spaces in the dwg file name.

VidCAD Reporter

-New ISO Report Filter - All Reports are now identified as ISO or ANSI and users can choose which groups of reports to view based on the filter selection based on

-Enhanced the filtering selection of "Exclude Unassigned Cores" by moving it from the filter area to the report properties.

-Enhanced the filtering/display of multicore cables and/or single core cables only by moving the filters to the report properties.

-New filter in cable reports and labels to show/hide multicore Add report properties to include only sheaths, only pairs, or both from multicore cables.

-Changed the default for multicore cables to output core number instead of core color.

-Resolved advanced filter item selection to display available content on single click properly.

-Resolved issue with reporter timing out on larger projects.

-Resolved the use of decimal and digit grouping symbols for metric users.

Equipment

-Enhanced speed of the Equipment Recall window for large projects that were running slow if the project had many jack panels.

-Resolved issue that was causing InterCONNECT to fail to routers with long I/O names.

-Resolved issues with Redline to feathers and Redline not updating all drawings.

Cables

-Resolved issue with Cable Renumber and Jack Renumber where some users project drawings that were closed were not being updated.

-Resolved typo on the Feather Drawing Name Update window.

-Resolved issue with Cable Types window to force Save when the exit button is selected.

-Resolved issue with Redline not updating cable database properly.

-Resolved issue with the Redline Query function where Jacks and Router sysnames were not being filtered out.

-Resolved fatal error caused by canceling out of the library router creation process.

-Resolved issue where Bluelined cables were not always being removed from project cable database.

Visio

-Resolved issue with drawing name giving invalid drawing name message during drawing creation.

-Resolved issue with Categorized Drawing view showing Visio drawings while in Visio is NOT selected in VidCAD Options.

Other

-Resolved issue with the Refresh Log command that was causing it to remove source out and desti in data in the rdequip table for cables going to feathers.

-Resolved issue where some drawings were opening with invalid layer names during drawing start up.
